Leaf-Spine Fabric & EVPN/VXLAN Services

Architecting scalable, automated, and resilient data center networks built for the demands of private cloud, AI, and modern applications.

Advanced Network Infrastructure and Design Services

Is Your Legacy Network a Bottleneck to Innovation?

Legacy three-tier architectures weren’t built for today’s data center demands. Designed around north-south traffic, they’re rigid, inefficient, and dependent on outdated protocols like Spanning Tree that waste link capacity and slow everything down.

Modern environments, from virtual machines to containers and AI workloads, move east-west, with traffic constantly flowing between systems. That shift exposes serious limits: congestion, poor mobility, and brittle scaling that slows innovation.

Even some early leaf-spine designs, especially Gen1 topologies or proprietary ACI implementations, can’t keep up. They lock you into static policy models, limited interoperability, and bandwidth ceilings that make 40G/10G look like dial-up in a 400/800G world. Whether you’re hitting capacity walls, struggling to scale out pods, or trying to escape closed architectures, it’s time to evolve.

If your data center network can’t adapt, it’s not just underperforming; it’s holding you back.

Modern Leaf Spine Network ArchitectureModern Leaf Spine EVPN Network Architecture



Our Approach to Building Modern Data Center Fabrics

Intelligent Visibility designs and implements next-generation data center networks using a proven two-layer architecture.

We build a highly scalable and resilient Layer 3 Leaf-Spine fabric as the underlay, providing a robust transport foundation.

On top, we deploy a flexible and intelligent EVPN/VXLAN overlay, enabling seamless Layer 2 connectivity, workload mobility, and multi-tenancy across the entire fabric.

Massive Scalability

Massive Scalability

Resilience

High    Resilience

agile-methodology

Unmatched Agility

trust

Secure Segmentation

automation

Automation DevOps/IaC

network-monitoring

Observability

Key Components

High-Performance Leaf-Spine Underlay

The foundation of our design is a robust Layer 3 routed underlay built on a Clos-based topology. Every leaf switch connects to every spine switch, creating a non-blocking fabric where all links are active. This architecture uses Equal-Cost Multipath (ECMP) routing to load balance traffic and provide predictable, low-latency performance for all east-west traffic flows. Scaling is simple and linear: add leaf switches for more server ports and spine switches for more bandwidth, without re-architecting the network.

Flexible EVPN/VXLAN Overlay

We decouple the logical network from the physical infrastructure using an EVPN/VXLAN overlay. VXLAN encapsulates Layer 2 frames into Layer 3 packets, allowing you to extend L2 segments anywhere across the data center fabric, or even between data centers. BGP EVPN serves as the modern, standards-based control plane, efficiently distributing endpoint reachability information and reducing reliance on inefficient flood-and-learn mechanisms. This enables true workload mobility, robust multi-tenancy, and simplified network management.

Integrated Automation and Orchestration

Modern fabrics are designed for automation from Day 0. We leverage the powerful APIs and automation platforms of our partners to deliver Infrastructure-as-Code (IaC) and NetDevOps capabilities. From zero-touch provisioning of new switches to automated configuration and compliance validation, we build networks that reduce manual effort, minimize human error, and accelerate service delivery.

Our Networking Technology Partners



Connecting Technical Capabilities to Business Outcomes

Technical Feature Business Benefit
Leaf-Spine Architecture Massive, Non-Blocking Scalability. Seamlessly scale your network to support business growth and new applications without performance degradation or costly redesigns. All links are active, maximizing your infrastructure investment.
EVPN Control Plane Reduced Operational Complexity & Greater Stability. Eliminate inefficient broadcast flooding and complex protocols like Spanning Tree. EVPN provides a scalable, intelligent control plane that simplifies management and improves overall network resilience.
VxLAN Tunneling Ultimate Agility & Workload Mobility. Place any application on any server in any rack, and move virtual machines or containers across the data center without changing IP addresses or network configurations, enabling true application portability.
Multi-Tenancy & Segmentation Enhanced Security & Compliance. Logically isolate traffic for different tenants, applications, or environments (e.g., development, production) on the same physical infrastructure, reducing the attack surface and simplifying compliance mandates.
Standards-Based Design No Vendor Lock-In & Future-Proof Foundation. Our architectures are built on open standards like BGP, ensuring interoperability and providing a flexible foundation that can evolve with your business and integrate new technologies.

Our End-to-End Lifecycle Partnership

You're in luck! Use this module to show content in chronological order using a neat scrolling effect that displays your events one by one.

Discovery & Strategy

We start with collaborative workshops to deeply understand your current challenges, application requirements, and future business objectives.

Architectural Design

Our experts create detailed High-Level (HLD) and Low-Level (LLD) design documents, providing a complete blueprint for a network tailored to your needs

Implementation & Migration

Our certified engineers execute a phased rollout and migration plan, meticulously managing the process to minimize disruption and ensure a seamless transition from your legacy environment.

Validation & Handover

We conduct rigorous testing to validate that the new fabric meets all performance and resilience requirements, followed by comprehensive as-built documentation and knowledge transfer to your team

Ongoing Optimization Aegis Managed Services

We offer proactive monitoring, management, and support through our Aegis platform to ensure your network operates at peak performance and continues to evolve with your business.

See Our Expertise in Action

Data Center Modernization for Private Cloud

For enterprises building a private cloud, a Leaf-Spine EVPN/VXLAN fabric provides the agile, scalable, and automated foundation required. It allows for the seamless integration of compute and storage resources, supports self-service provisioning for DevOps teams, and enables the secure multi-tenancy needed to host diverse applications and business units.

A leading software development firm partnered with us to replace its aging 3-tier network. The new Arista-powered fabric reduced network storage latency by 20% and enabled them to deploy new virtualized services in minutes instead of weeks across a global private cloud, wherever the workload needed to be located.

High-Performance Computing (HPC) & AI/ML Workloads

AI and HPC workloads demand ultra-low latency and high-bandwidth, lossless networking. A properly designed Leaf-Spine fabric eliminates network bottlenecks and provides the predictable performance necessary for data-intensive training models and parallel processing tasks, ensuring expensive GPU clusters are never waiting on the network.

Multi-Site Data Center Interconnect (DCI)

EVPN/VXLAN can be extended across multiple physical data centers, creating a single, unified network fabric. This simplifies disaster recovery strategies, enables active-active data centers, and allows for seamless mobility of virtual machines and applications between sites for load balancing or maintenance without service interruption.

Ready to Build Your Future-Ready Network?

Partner with Intelligent Visibility to move beyond the constraints of legacy networking. Let's build a modern, secure, and agile network that accelerates your business objectives and provides a durable competitive advantage.
