Why RoCE Matters for AI

RoCEv2 transforms Ethernet into a high-performance fabric for distributed AI, minimizing latency, maximizing GPU throughput, and reducing model training times.

The engine of modern Artificial Intelligence and Machine Learning (AI/ML) is data – vast quantities of it, constantly in motion. Training sophisticated AI models, particularly large language models (LLMs) and complex deep learning algorithms, involves an unprecedented scale of parallel processing across hundreds or even thousands of Graphics Processing Units (GPUs). In AI networking, the difference between TCP and RoCEv2 isn’t subtle, it’s measured in GPU idle time, cost per training run, and time to insight.

In these intricate GPU clusters, every microsecond of latency and every dropped packet translates directly into wasted compute cycles, prolonged training times, and increased operational costs. Traditional TCP/IP networking, with its inherent overheads and potential for packet loss, can become a significant bottleneck, starving expensive GPUs of the data they need to operate at peak efficiency.

This is where RoCEv2 (RDMA over Converged Ethernet version 2) emerges as a transformative technology. RoCEv2 enables Remote Direct Memory Access (RDMA) over standard Ethernet networks. RDMA allows one server to directly access the memory of another server without involving the CPU or operating system of either, leading to:

Zero-Copy Operations: Data is transferred directly from the network interface card (NIC) to GPU memory (or application memory), bypassing CPU involvement and system memory copies, drastically reducing overhead.
Ultra-Low Latency: By minimizing software stack processing, RoCEv2 significantly cuts down on communication latency, crucial for tightly coupled AI training workloads.
High Throughput: RoCEv2 is designed to maximize bandwidth utilization, ensuring that high-speed network links are fully leveraged.
For AI/ML, RoCEv2 isn't just an improvement; it's a foundational element for building high-performance GPU fabrics capable of handling the relentless data exchange required to train today's and tomorrow's AI models effectively.

What Makes RoCEv2 AI-Ready?

While the core benefits of RDMA are clear, RoCEv2 possesses specific characteristics that make it particularly well-suited for the demanding environment of AI networking:

Layer 2 or Layer 3 Transport: RoCEv2 offers deployment flexibility. It can operate at Layer 2 (within a single broadcast domain) or, more commonly for large-scale AI clusters, at Layer 3. Routable RoCE (RRoCE) allows RDMA communication to traverse IP subnets, enabling the construction of large, segmented, and scalable GPU fabrics without being constrained by Layer 2 domain limitations. This is vital for building multi-rack or even multi-data hall GPU clusters.
Compatibility with Network Overlays (with a Lossless Underlay): Modern network designs often utilize overlay technologies like VXLAN for network virtualization, segmentation, and multi-tenancy. RoCEv2 can operate effectively in conjunction with such overlays. However, a critical prerequisite is that the physical underlay network must be engineered for lossless transport. This means the underlay must guarantee that RoCEv2 packets are not dropped due to congestion, as RDMA protocols are highly sensitive to packet loss. (More on this in Section 5).
Support for Scale-Out GPU Pods: AI infrastructure is frequently designed in modular "pods" or "superpods" – standardized units of GPUs, compute, and networking that can be replicated to scale out training capacity. RoCEv2's ability to operate efficiently at scale, especially in Layer 3 deployments, makes it ideal for interconnecting these pods and enabling them to function as a cohesive, high-performance training fabric. This supports the massive parallelism required for distributed training jobs that span numerous GPUs.
Broad Ecosystem Support: RoCEv2 is a standards-based technology with wide support from NIC vendors, switch manufacturers, and AI framework developers, ensuring interoperability and a growing ecosystem of compatible hardware and software.

These attributes collectively position RoCEv2 as the leading choice for building the high-speed, low-latency, and scalable networks that modern AI workloads demand.

Design Considerations for RoCEv2 in AI Clusters

Successfully deploying RoCEv2 for AI workloads requires careful network design and meticulous configuration. Achieving true lossless transport and optimal performance hinges on several key considerations:

Explicit Congestion Notification (ECN) and Priority Flow Control (PFC) Tuning:

ECN: Allows network switches to mark packets when congestion is beginning, rather than dropping them. RoCEv2-capable NICs and switches use ECN feedback to signal senders to reduce their transmission rate, preventing buffer overflows and packet loss. Proper ECN threshold configuration on switches is crucial.
PFC (IEEE 802.1Qbb): Provides a link-level flow control mechanism that can pause traffic for specific CoS (Class of Service) priorities to prevent packet drops due to buffer exhaustion. RoCEv2 traffic is typically assigned a dedicated, lossless priority, and PFC is enabled for this priority on all network devices (NICs, switches) in its path. Careful planning of PFC buffer allocation and ensuring end-to-end consistent PFC configuration are essential to avoid issues like PFC storms or deadlocks.

Switch Compatibility and Capabilities:

Deep Buffers: AI workloads, particularly during distributed training, can generate bursty traffic patterns and incast scenarios (many senders transmitting to one receiver simultaneously). Switches with sufficiently deep, dynamically shared buffers are critical to absorb these microbursts without dropping packets, even with ECN and PFC in place. For example, switch ASICs like those found in the Arista Jericho family are known for their deep buffering capabilities, making them well-suited for demanding RoCEv2 environments.
Low Latency & High Port Density: Switches must offer consistently low port-to-port latency and support high-density configurations (e.g., 100G, 200G, 400G, and emerging 800G ports) to match the bandwidth requirements of modern GPUs.
Predictable Performance: The switch fabric should deliver predictable performance under heavy load, without unexpected jitter or performance degradation.

Flow Control Best Practices for Distributed Model Training:

Congestion Control Algorithms: RoCEv2 relies on congestion control algorithms implemented in the NICs (e.g., DCQCN - Data Center Quantized Congestion Notification) that react to ECN signals. Ensuring NICs and their drivers are up-to-date and properly configured for the specific network environment is vital.
Traffic Mapping and QoS: Map RoCEv2 traffic to a dedicated, lossless CoS queue with strict priority. Other traffic types (management, storage if separate) should be mapped to different queues to prevent interference.
Monitoring and Telemetry: Implement comprehensive monitoring of PFC pause frames, ECN markings, buffer utilization, and queue depths on switches and NICs. This visibility is essential for verifying lossless behavior, troubleshooting issues, and fine-tuning the network.
Physical Layer Integrity: High-quality cabling (e.g., well-terminated fiber optics) and optics are fundamental. Errors at the physical layer can lead to packet corruption or loss, undermining the entire lossless design.

Designing a RoCEv2 fabric for AI is an exercise in precision engineering. Each component must be selected, configured, and validated to work harmoniously to deliver the consistent, lossless performance that AI workloads depend on.

Common Pitfalls to Avoid in RoCEv2 AI Deployments

While RoCEv2 offers immense performance benefits, achieving them requires diligence. Several common pitfalls can undermine a RoCEv2 deployment, leading to suboptimal performance or even complete communication breakdown:

Lossless Configuration Mismatches:

The Problem: PFC, ECN, and CoS settings must be configured consistently across every device in the RoCEv2 traffic path – NICs, switches, and even routers if traversing L3 boundaries. Any mismatch (e.g., PFC enabled on one end but not the other, different ECN thresholds, incorrect CoS-to-queue mapping) can lead to packet drops, PFC storms (where pause frames propagate uncontrollably), or deadlocks.
Mitigation: Rigorous configuration auditing, standardized templates, and automated configuration management are crucial. Thorough end-to-end testing before deploying workloads is essential.

Overprovisioning Without Effective Congestion Control:

The Problem: Simply throwing more bandwidth at the problem (e.g., upgrading to faster links) without robust and properly tuned congestion control (ECN, DCQCN) can exacerbate issues. Uncontrolled bursts can still overwhelm buffers, leading to packet loss if congestion signals are not acted upon quickly and effectively.
Mitigation: Focus on an end-to-end congestion management strategy. Ensure ECN is working correctly, NICs are responsive to congestion signals, and switch buffers are adequate for the expected burstiness.

Ignoring Quality of Service (QoS) and Traffic Isolation:

The Problem: Not all traffic in an AI cluster is RoCEv2. Management traffic, general IP traffic, and potentially storage traffic (if not using RoCE for storage) share the same physical infrastructure. Without proper QoS, lower-priority traffic can interfere with latency-sensitive RoCEv2 flows, or RoCEv2 traffic could starve out other essential services.
Mitigation: Implement a clear QoS policy. Assign RoCEv2 to a dedicated high-priority, lossless queue. Ensure other traffic types are appropriately classified and queued to prevent them from impacting RoCEv2 performance while still receiving their required service levels.

Insufficient Telemetry and Visibility:

The Problem: Operating a lossless network "blind" is risky. Without detailed telemetry on PFC pause frames (sent/received per port), ECN markings, buffer utilization, queue depths, and RDMA-specific counters from NICs, it's nearly impossible to verify correct operation, troubleshoot problems, or proactively identify emerging congestion.
Mitigation: Leverage advanced network monitoring and telemetry solutions. Modern network operating systems provide granular, streaming telemetry. Correlate switch-level data with NIC-level RDMA statistics for a complete picture.

Inadequate Buffer Sizing or Configuration:

The Problem: Even with PFC and ECN, switches need adequate buffering to handle microbursts and transient congestion. Misconfiguring buffer allocations (e.g., static, small shared buffers) can lead to drops.
Mitigation: Choose switches with sufficient, dynamically shared buffer architectures. Understand the buffering capabilities and tune them according to workload characteristics and network topology.

MTU Mismatches:

The Problem: Inconsistent Maximum Transmission Unit (MTU) sizes across the network path can cause packet fragmentation or drops, severely impacting RoCEv2 which expects consistent MTU for optimal performance.
Mitigation: Ensure a consistent MTU (often jumbo frames, e.g., 9000+ bytes) is configured on all NICs, switches, and router interfaces involved in RoCEv2 communication.

Avoiding these pitfalls requires a holistic approach to network design, meticulous configuration, continuous monitoring, and a deep understanding of both RoCEv2 mechanics and the specific demands of AI workloads.

Pairing RoCEv2 with EVPN/VXLAN for Enhanced AI Fabrics

As AI clusters scale, the need for network virtualization, multi-tenancy, and flexible workload placement becomes increasingly important. This is where combining a high-performance RoCEv2 underlay with an EVPN/VXLAN overlay offers a powerful and sophisticated solution.

Underlay/Overlay Separation:

RoCEv2 Lossless Underlay: The physical network (the underlay) is meticulously engineered for lossless transport using RoCEv2, ECN, and PFC as described previously. Its primary role is to provide high-bandwidth, low-latency, drop-free connectivity between physical servers hosting GPUs.
EVPN/VXLAN Overlay: On top of this high-performance underlay, an EVPN/VXLAN overlay can be deployed. VXLAN provides Layer 2 network virtualization, allowing the creation of millions of isolated logical networks (VNIs) that can span across the physical infrastructure. EVPN (Ethernet VPN) serves as the standards-based control plane, using BGP to distribute MAC address and IP routing information for these virtual networks, enabling scalable and efficient communication within and between VNIs.

Benefits of the Combined Approach for AI:

Network Segmentation and Multi-Tenancy: Different AI projects, user groups, or development stages can be isolated into separate VXLAN segments, enhancing security and preventing interference, all while sharing the same physical RoCEv2 fabric.
Workload Mobility and Flexibility: While less common for tightly coupled GPU training jobs that are often statically placed, the overlay can provide flexibility for auxiliary services or management networks associated with AI clusters.
Simplified Underlay Management: The underlay can be kept relatively simple, focused purely on high-performance IP transport and lossless characteristics. The complexity of managing MAC addresses and logical network topologies is handled by the EVPN control plane in the overlay.
Scalable Fabric Management: EVPN provides a robust and scalable control plane for managing connectivity in large AI fabrics, integrating seamlessly with the Layer 3 RoCEv2 underlay.

Design Alignment Considerations:

MTU: The underlay MTU must accommodate the VXLAN header overhead (typically 50-54 bytes) in addition to the RoCEv2 payload. This means underlay interfaces usually require an MTU setting of 9216 bytes or higher to support jumbo frames for RoCEv2 encapsulated within VXLAN.
QoS Propagation: QoS markings (e.g., DSCP values) from the inner RoCEv2 packet should ideally be mapped to the outer VXLAN packet's DSCP field by the VXLAN Tunnel Endpoints (VTEPs). This ensures that the underlay switches can prioritize VXLAN-encapsulated RoCEv2 traffic correctly based on the underlay's QoS policies.
VTEP Performance: The devices acting as VTEPs (typically top-of-rack switches or specialized NICs) must have sufficient processing power to handle VXLAN encapsulation/decapsulation at line rate for high-bandwidth RoCEv2 traffic without adding significant latency.
Pairing a meticulously designed lossless RoCEv2 underlay with a flexible EVPN/VXLAN overlay provides a best-of-both-worlds architecture for large-scale AI networks, delivering both raw performance and sophisticated network virtualization capabilities.
(Internal Link Suggestion: For more details on how EVPN/VXLAN enhances AI network fabrics, see our dedicated page

When NOT to Use RoCEv2 in AI

While RoCEv2 is a game-changer for many AI workloads, it's not a universal solution. There are scenarios where the benefits might be marginal or the complexity and cost of implementation outweigh the advantages

Latency-Insensitive Inference Workloads:

Scenario: Many AI inference workloads (using trained models to make predictions) are less sensitive to inter-node communication latency than training workloads. Inference tasks might involve processing single inputs or small batches, where the network communication overhead is a smaller fraction of the total processing time.
Consideration: For such workloads, standard TCP/IP networking over a well-provisioned Ethernet fabric might be sufficient and simpler to manage. The added complexity of tuning a lossless RoCEv2 network may not yield proportional performance gains.

Environments Without Properly Tuned Lossless Underlays:

Scenario: RoCEv2 is fundamentally reliant on a truly lossless underlying network. If an organization cannot commit to the rigorous design, meticulous configuration (PFC, ECN), specialized hardware (deep-buffered switches), and continuous monitoring required to guarantee lossless behavior, attempting to run RoCEv2 will likely lead to poor performance and instability.
Consideration: In such cases, alternative high-performance interconnects that are more tolerant of some packet loss, or even optimized TCP/IP, might be a more pragmatic choice, despite not reaching RoCEv2's peak performance. The operational overhead of a poorly implemented RoCEv2 network can quickly negate any theoretical benefits.

Extremely Small-Scale or Development Clusters:

Scenario: For very small setups (e.g., a single server with multiple GPUs or a couple of interconnected servers for experimentation), the full RoCEv2 setup with dedicated lossless infrastructure might be overkill.
Consideration: Simpler networking might suffice, with the understanding that it won't scale to production training levels. However, even here, if GPU-direct RDMA is desired, RoCEv2 could be used if the small network (e.g., point-to-point or a single switch) can be made lossless.

Cost Constraints Outweighing Peak Performance Needs:

Scenario: Building and maintaining a true lossless RoCEv2 fabric can involve higher upfront costs for specific switches and NICs, and requires more specialized networking expertise.
Consideration: If budget constraints are severe and the AI workloads can tolerate slightly lower performance, a decision might be made to opt for a more conventional Ethernet setup. However, it's crucial to accurately model the cost of longer training times versus the investment in a RoCEv2 network.

The decision to use RoCEv2 should be based on a clear understanding of the workload's sensitivity to latency and packet loss, the scale of the deployment, and the organization's capability and commitment to implementing and managing a lossless network fabric correctly.

If you are evaluating RoCEv2 for Storage Networking workloads, explore our overview of those architectures here.
